Vizion Collector

Product Description

The Collector is a two way transmitting module that sits within a localised network of nodes. Each collector has a maximum capacity of up to 250 nodes within a 3km radius. In practice, working numbers may be less due to localised conditions. The collector scans the local network for faults and modifies control regimes according to the type of activation and time profile selected. Each collector has the facility to adopt any nodes within its range that are not already assigned to another collector or if an adjacent collector ceases to operate for any reason (up to the collectors maximum capacity).

Through the WiMAC protocol – a secure, wireless communication channel – the Collector, has two-way communication with the Nodes on all street lights within its range. Each Collector has a maximum capacity of up to 250 Nodes within a 3km radius. In practice, working numbers may be less due to localised conditions. The Collector collects the information from all the street lights in its area and, using GPRS, sends the information to the Vizion Host. The Collector also receives messages from the Vizion Host and transmits them to the individual Nodes on the street lights. The Collector ensures that the Nodes are operating according to their schedule.

Specifications

Appropriate Fitting fundamentals: 20mm hole, washer & nut seal
Onsite Protection: Externally sealed enclosure
IP rating: IP 66 correctly fitted
Enclosure material: Polycarbonate
Operating temperature range: -20 – +55°C
Power Supply requirements: Supplied from Vizion ZEDA Driver or ZEBC Ballast
Server Communications: Quad band GSM / GPRS, integral antenna
Receiver classification: Class 2
Device classification: Class 2
Performance Compliance: EN300 220 / REC 70-03 Annex1 (g1)Manufactured: UK
Optional remote power supply

Dimensions

Height – 145mm
Width – 135mm
